Halogen Free Flame Retardant (HFFR) wires are designed to limit the spread of flames while preventing the release of harmful halogen gases, making them a safer and more environmentally responsible choice for modern electrical installations. These wires help reduce smoke toxicity and improve safety in fire-prone situations.
Built with high-grade insulation that resists ignition, HFFR wires enhance fire safety while maintaining reliable electrical performance. They are suitable for residential, commercial, and industrial applications where low smoke emission and reduced toxicity are essential.
Engineered for durability and consistent operation, these halogen-free flame-retardant wires meet stringent safety standards and perform reliably under varying conditions. By combining safety, efficiency and long-term performance, HFFR wires support dependable electrical systems across a wide range of environments.
Salient Features
Non-Toxic Zero Halogen
HFFR wires minimize toxic gas release (<0.5%), thus offering 10x safer performance than FRLSH wires. These wires ensure improved air quality during emergencies, enhancing survival and rescue opportunities.
Environment Friendly
In accordance with green building standards for sustainable construction.
High Visibility in Fire Emergencies
HFFR wire provides superior light transmission (over 70%) during fires, significantly reducing smoke and enhancing visibility for safer evacuations compared to ordinary PVC cables.
101% Copper Conductivity
Crafted from pure ETP-grade annealed copper with 99.97% purity, this material offers exceptional conductivity, resulting in superior energy efficiency, minimized losses, and consistent performance.
Anti-Termite and Anti-Rodent
Featuring specialized insulation, these wires effectively repel rodents and termites, ensuring long-lasting performance and lower maintenance costs. The anti-termite/rodent feature is applicable for 12 months from the invoice date.
REACH Compliant
These wires comply with REACH (Registration, Evaluation, Authorization, and Restriction of Chemicals) standards, ensuring they are free from harmful substances and prioritizing safety, health, and environmental sustainability.
RoHS Compliant - Eco-friendly
These wires are RoHS-compliant according to EU Directive (2015/863) and are free from hazardous substances such as lead and mercury. Made with eco-friendly materials, they ensure safety for human health while promoting a sustainable and greener environment.
| Nominal Cross Sectional Area | No. of strands/Max. dia. of each strand | Nominal Insulation Thickness | Max. Overall Diameter | Maximum DC Conductor Resistance at 20°C | Current Carrying Capacity (2 cables in single phase) | |
|---|---|---|---|---|---|---|
| Bunched and Enclosed in Conduit or Trunking | Clipped Direct to a Surface or on a Cable Tray, Bunched and Unenclosed | |||||
| 1 | 14/0.31 | 0.70 | 3.20 | 18.1 | 14 | 15 |
| 1.5 | 22/0.31 | 0.70 | 3.30 | 12.1 | 17 | 19 |
| 2.5 | 36/0.31 | 0.80 | 4.60 | 7.41 | 21 | 25 |
| 4 | 56/0.31 | 0.80 | 4.80 | 4.95 | 26 | 32 |
| 6 | 84/0.31 | 0.80 | 5.30 | 3.30 | 33 | 38 |
