TpX Distribution Boards by Torrent Electricals are designed for reliable power distribution with a clean, modern enclosure design. These Distribution Boxes provide enhanced safety, proper cable management, and long-term durability for residential and commercial electrical systems.
The TpX range includes TPN DB configurations suitable for higher load applications, offering secure housing and easy accessibility. With precision-built construction and high safety standards, TpX distribution boards ensure efficient power control while maintaining a neat and professional electrical setup.
Certifications
Torrent Electricals Ltd. ISO45001
Torrent Electricals Ltd. ISO14001
Torrent Electricals Ltd. ISO9001
Standards
IEC 61439-3
Technical Specifications
| CHARACTERISTICS | TEL DBs |
|---|---|
| No. of Ways | 4, 6, 8, 12, 16, 18, 20 (SPN), 4, 6, 8, 12 (TPN) |
| Type of Installation | Surface and Flush mounting |
| Doors and IP Rating | Double (IP42) |
| Door Options | Reversible for Double Door |
| Removable Gland Plates | Top and Bottom |
| Impact Protection | IK09 (Double Door) |
| Busbar Rating | 63A |
| Voltage Rating | 240 / 415V AC |
| Incoming Options | MCB / RCCB / Isolator |
| Outgoing Option | Single Pole MCB |
| Neutral Bar Terminal Size | 28 sq. mm |
| Earthing Bar Terminal Size | 28 sq. mm |
| Dielectric Strength | 2.5 kV |
| Operating Temperature Range | -5 to 55°C |
| Box Thickness | 1 mm |
| Color | White |
| Reference Standard | IS/IEC 61439-3 |
